Piston Rod (For Hydraulic Cylinder)
High-Performance Hydraulic Cylinder Piston Rods
Our precision-engineered piston rods for hydraulic cylinders are manufactured using premium-grade carbon and alloy steels to deliver exceptional strength, durability, and surface finish. Designed for high-load and high-pressure environments, these rods ensure reliable and efficient performance in demanding hydraulic systems.
Key Features
- High tensile strength for heavy-duty hydraulic applications
- Hard chrome plated surface for superior corrosion resistance
- Smooth finish for reduced friction and extended seal life
- Excellent wear and abrasion resistance
- Precision ground for dimensional accuracy and performance
Raw Materials
- Carbon Steel (EN8 / C45 / SAE 1045)
- Alloy Steel (EN19 / SAE 4140)
- Mild Steel (MS)
- Stainless Steel (SS)
Applications
- Hydraulic Cylinders
- Construction Equipment
- Industrial Machinery
- Heavy Engineering Applications
- Material Handling Equipment
| APPLICATION AREA | DETAILS |
|---|---|
| 🔩 Hydraulic Cylinders | Core component used for linear motion and force transmission in hydraulic cylinder systems |
| 🏗 Construction Equipment | Widely used in excavators, loaders, cranes, and other heavy-duty construction machinery |
| 🏭 Industrial Machinery | Ensures smooth and reliable operation in high-load industrial machines |
| 🚜 Material Handling Equipment | Used in forklifts, lifting systems, and handling equipment for controlled movement |
| ⚙️ Heavy Engineering Applications | Suitable for high-pressure and heavy-load mechanical systems |
| 🤖 Automation Systems | Supports precise linear motion in automated and semi-automated machinery |
| Parameter | Details |
|---|---|
| Product Name | Piston Rod (For Hydraulic Cylinder) |
| Material | EN8, C45, SAE 1045, EN19, SAE 4140, Stainless Steel (SS) |
| Surface Finish | Hard Chrome Plated, Mirror Finish |
| Surface Hardness | 850 – 1100 HV |
| Chrome Plating Thickness | 20 – 30 Microns (or as per requirement) |
| Straightness | ≤ 0.2 / 1000 mm |
| Strength | High Tensile Strength |
| Corrosion Resistance | Excellent (Chrome Coated) |
| Wear Resistance | High – Suitable for Heavy Duty Applications |
| Process | Induction Hardened, Chrome Plated & Precision Ground |
| Applications | Hydraulic Cylinders, Construction Equipment, Industrial Machinery |
| Customization | Available as per drawings & specifications |
